Manufacturer: MI Windows and Doors
MI Windows and Doors · V3000
V3000 Series 1617 Sliding Glass Door
V3000 Series vinyl sliding glass door with a frame that assembles on the jobsite, in two-, three- and four-panel configurations with impact-resistant and DP50 options.
- Material
- Vinyl
- Application
- New construction, Replacement
- Impact rated
- Yes
Available colors
White · Almond · Clay · Black · Bronze · Cocoa · Cream · Forest Green · Silver
Specifications
Product details
| Model | 1617 |
|---|---|
| Shipping | Frame assembled on the jobsite (MI's knock-down version of the 1615); see MI 1617 assembly instructions |
| Panels | 2, 3 or 4 |
| Frame types | Finless, Flange, Fin |
| Glass | Dual-pane Low-E, Argon + Low-E; warm-edge spacer; impact-resistant and DP50 options |
| Interlock | Vinyl interlock on standard doors; aluminum interlock on impact-resistant and DP50 doors |
| Interior colors | White, Almond, Clay |
| Grids | Grids between Glass - Flat, Sculptured Grid |
| Grid patterns | None, Standard, Standard Half, Perimeter Corner, Perimeter Pane, Valance |
| Options | Blinds-between-glass, impact-resistant, DP50 |
Sizes
Standard sizes
- 2-panel XO/OX
- 3-panel
- 4-panel OXXO
- Same size range as the 1615 (MI 1615/1617 size guide)
